Characteristics and Application
Model | Name | Performance | Application scope | ||
Filtration accuracy | Water removal rate | Oil mist removal rate | |||
HC series | Centrifugal oil-water separator | 3μ | 99% | 40% | Separator for the rear cooler, separation of the freeze dryer, front filter of the main road. |
HT series | Main crossing filter | 1μ | 100% | 70% | Pneumatic tool pre filter, precision filter pre filter, adsorption dryer front and rear filter, air system main pipe filter. |
HA series | Micro oil mist filter | 0.01μ | 100% | 99.999% | The use of lubricated air compressor to provide oil-free air to meet the needs of precision instruments, painting, food and food packaging and electronics industry needs. |
HH series | Activated carbon adsorption filter | 0.01μ | Residual oil rate 0.003ppm | Food, hospital and pharmaceutical plants, diving to protect the respiratory gas, the University of the filter after the filter. Activated carbon adsorption filter can remove oil vapor. | |
Technical parameter
Working medium | Compressed air or non corrosive gas |
Inlet temperature | <66℃ |
Working pressure | Standard 0.7Mpa, maximum 0.95Mpa (below 4.0Mpa order accepted) |
Initial pressure drop | >0.015Mpa |
Working life | HC/HT/HA：8000h； HH：2000h （to the pressure drop up to 0.07Mpa.） |
Moisture load | HC:25000ppm， HT：2000ppa，HA：100ppm |
Select accessories | Automatic drainage device, electronic drainer, differential pressure meter |
